| Display | Interface: 1 HDMI, 1 VGA
Resolution:HDMI: 3840 x 2160 , 1920 x 1080 , 1280 x 1024, 1280 x 720 , 1024 x 768
VGA: 1920 x 1080 , 1280 x 1024, 1280 x 720 , 1024 x 768
Decoding Capacity:4-ch@8MP(30fps), 16-ch@1080P(30fps)
Multi-Screen Display: 1/4/8/9/16/25/36
OSD: Camera title, Time, Camera lock, Motion detection, Recording |
| Network | Interface:1 RJ-45 Ports (10/100/1000Mbps)
PoE: N/A
Network Function: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4IP
Maximum User Access: 128 users
Smart Phone: iPhone, iPad, Android
Interoperability
ONVIF 2.4, SDK, CGI
|
| Playback and Backup | Sync Playback: 1/4/9/16
Search Mode: Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network
|
| Recording | Compression: Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
Resolution: 12MP with 15fps, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1, CIF with 30fps
Bit Rate: Max 200 Mbps Bit rate input
Record Mode: Manual, Schedule (Regular, MD(Motion Detection) , Alarm, IVS), Stop
Record Interval: 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Storage | Internal HDD: 2 SATA III Ports, up to 6TB capacity for each HDD
HDD Mode: Single
eSATA: N/A |
| System | Main Processor: Quad-core embedded processor
Operating System: Embedded LINUX
|
| Video and Audio | IP Camera Input: 32 Channel
Two-Way Talk: 1 Channel Input, 1 Channel Output, RCA |
